Opis
The BASS series offers a professional and compact passive and active subwoofers range becoming the perfect choice for sound reinforcement challenges demanding high SPL and natural sounding bass response designed to enhance the ultra-low bass of an existing PA system.
Key Features
- Bass reflex subwoofer
- 1x 15″ (4in VC) LF EU transducer
- 1200W AES / 7000W Peak power
- 2x NL4 connected in parallel
- Versatile, compact and coherent subwoofer
- Made for an impact bass
- Recesses on the top to facilitate the stacking
- Rugged and durable 18mm birch plywood construction
- Powder coated custom perforated steel grille
Tech Specs
| Type | Compact PASSIVE subwoofer | |
| Enclosure Design | Reflex Loaded | |
| Power Output (RMS) | 1200W (AES) 2400W (Program) 7000W (Peak) | |
| Frequency Range | 32Hz – 250Hz (-10dB) | |
| Nominal Impedance | 8 Ohm | |
| Transducer Type | 15″ (4in VC) LF EU transducer | |
| Crossover Frequency | N/A | |
| Max. SPL (peak) | 126dB @ 1m (continuous) 132dB @ 1m (peak) | |
| Connector | 2x NL4 in parallel | |
| Construction | 18mm birch plywood with polyurea coating | |
| Grille | Custom perforated metal grille w/ acoustic foam | |
| Installation / Rigging / Flying | 4 rubber feet, 2 side handles Ø35mm pole mount socket Prepared for stacking | |
| Dimensions (WxDxH) | 590x590x440mm 23.23×23.23×17.32in | |
| Weight | 35Kg 77.16lb |
