Opis
The BASS series offers a professional and compact passive and active subwoofers range becoming the perfect choice for sound reinforcement challenges demanding high SPL and natural sounding bass response designed to enhance the ultra-low bass of an existing PA system.
This active version feature a powerful class D single channel amplifier delivering 3200W @ 4ohm connected to a fully programmable DSP providing low-ranging yet clearly defined bass response and rendering impulses with great accuracy in a very compact and robust enclosure. The amplifier module is prepared for universal 85-264Vac mains input and features various electronic protections.
Key Features
- Bass reflex ACTIVE subwoofer
- 2x 18″ LF (4in VC) European transducer
- Optimized for high SPL output
- 3200W class D, single channel amplifier
- 85-264Vac universal mains, all electronic protections
- Fully programmable built-in DSP, 4 selectable presets
- Heavy duty wheel casters on the back (optional)
- Rugged and durable 18mm birch plywood construction
- Powder coated custom perforated steel grille
Tech Specs
| Type | Compact ACTIVE subwoofer | |
| Enclosure Design | Bass reflex | |
| Power Output (RMS) | 2400W (AES) 4800W (Program) 9600W (Peak) | |
| Frequency Range | 27Hz – 180Hz | |
| Nominal Impedance | N/A | |
| Transducer Type | 2x 18″ (4in VC) LF EU transducer | |
| Crossover Frequency | DSP controlled with selectable presets 48KHz sampling frequency 24 bit AD/DA converter | |
| Max. SPL (peak) | 134dB @ 1m (continuous) 140dB @ 1m (peak) | |
| Amplifier type | Class D, single channel amplifier | |
| Amplifier output | 3200W (continuous) | |
| Input | XLR/Jack combo connector | |
| Output | XLR/M 3p connector | |
| Indicators | Power, signal/preset, clip | |
| Controls | Master level control, 4 selectable presets | |
| Feature | Cooling by convection | |
| AC Power Supply | Switching power supply, 85-264Vac | |
| AC mains connector | Neutrik® powerCON, Power-in (blue) / Power-out (grey) | |
| Protection | Over current and short circuit protection, thermal protection, DC output protection and HF protection (amplifier) | |
| Construction | 18mm birch plywood, textured polyurea coating | |
| Grille | Custom perforated metal grille w/ acoustic foam | |
| Installation / Rigging / Flying | 4 rubber feet, 4 side handles 4 swivel castors (optional) Prepared for stacking | |
| Dimensions (WxDxH) | 1070x830x580mm 42.13×32.68×22.83in | |
| Weight | 96Kg 211.64lb |
