Key Features
- Multipurpose 2-way active speaker
- Bass reflex trapezoidal enclosure
- 10″ (2in VC) MF + 1″ HF (1.73in VC) EU transducers
- User-rotatable CD horn 90°x60° for ideal dispersion
- Driven by a Class D, 2 channel amplifier
- Fully programmable DSP, 4 selectable presets
- Universal mains 85-264Vac
- Built-in Electronic protections for safe operation
- Integrated rigging system with 3x M10 inserts
- Rugged and durable 15mm birch plywood
Tech Specs
| Type | 2-Way active speaker | |
| Enclosure Design | Bass reflex trapezoidal enclosure | |
| Power Output (RMS) | 360W (EMS) 510W (Program) 900W (Peak) | |
| Frequency Range | 75Hz – 18kHz | |
| Transducer Type | 10″ MF (2in VC) EU transducer 1″ HF (1.73in VC) EU transducer | |
| Dispersion | CD horn, 90°x60° and 60°x90° User-rotatable | |
| Crossover Frequency | DSP controlled with selectable presets 48KHz sampling frequency 24 bit AD/DA converter | |
| Max. SPL (peak) | 125dB @ 1m | |
| Amplifier type | Class D, 2 channel amplifier | |
| Amplifier output | 800W + 400W (continuous) 1500W (peak) | |
| Input | XLR/jack combo connector | |
| Output | XLR/M 3p | |
| Indicators | Power, signal/preset, clip | |
| Controls | Master level control, 4 selectable presets | |
| Feature | Cooling by convection | |
| AC Power Supply | Switching power supply, 85-264Vac | |
| AC mains connector | Neutrik® powerCON, Power-in (blue) / Power-out (grey) | |
| Protection | Over current and short circuit protection, thermal protection, DC output protection and HF protection (amplifier) | |
| Construction | 15mm birch plywood, textured polyurea coating | |
| Grille | Custom perforated metal grille with acoustic foam | |
| Installation / Rigging / Flying | Ø35mm pole mount with 0° and 5° tilt 3x M10 flying points “U” bracket for horizontal and vertical installation | |
| Dimensions (WxDxH) | 320x350x550mm 12.60×13.78×21.65in | |
| Weight | 20Kg 40.09lb |
