Key Features
- Multipurpose 2-way passive speaker
- Bass reflex trapezoidal enclosure
- 12″ (2.5in VC) MF + 1″ HF (1.73in VC) EU transducers
- 2x NL4 connected in parallel
- User-rotatable CD horn 90°x60° for ideal dispersion
- Ø35mm pole mount with 0° and 5° tilt
- Integrated rigging system with 3x M10 inserts
- Rugged and durable 15mm birch plywood
- Powder coated custom perforated steel grille
Tech Specs
| Type | 2-Way passive loudspeaker | |
| Enclosure Design | Bass reflex trapezoidal | |
| Power Output (RMS) | 360W (EMS) 510W (Program) 900W (Peak) | |
| Frequency Range | 75Hz – 18kHz | |
| Nominal Impedance | 8Ohm | |
| Transducer Type | 10″ MF (2in VC) EU transducer 1″ HF (1.73in VC) EU transducer | |
| Dispersion | CD horn, 90°x60° and 60°x90° User-rotatable | |
| Crossover Frequency | 2000Hz | |
| Max. SPL (peak) | 125dB @ 1m | |
| Connector | 2x NL4 in parallel | |
| Construction | 15mm birch plywood, textured polyurea coating | |
| Grille | Custom perforated metal grille with acoustic foam | |
| Installation / Rigging / Flying | Ø35mm pole mount with 0° and 5° tilt 3x M8 flying points “U” bracket for horizontal and vertical installation | |
| Dimensions (WxDxH) | 320x350x550mm 12.60×13.78×21.65in | |
| Weight | 18Kg 39.68lb |
