Opis
Key Features
- Compact active 2-way speaker
- Front loaded enclosure
- 2x 5” (1.26in VC) rubber surround MF EU transducer
- 1″ (0.98in VC) HF EU transducer
- Constant directivity 60°x60° horn
- Driven by a Class D, 2 channel amplifier
- Fully programmable DSP, 4 selectable presets
- Universal mains 85-264Vac, SMPS
- Built-in Electronic protections for safe operation
- Integrated M8 threaded nuts for U-brackets (H&V)
- Ø35mm pole mount adapter (PMA205), tilt adjustment
- Rugged and durable 15mm birch plywood
- Powder coated custom perforated steel grille
Tech Specs
| Type | 2-way active speaker | |
| Enclosure Design | Front loaded | |
| Power Output (RMS) | 200W (AES) 280W (Program) 380W (Peak) | |
| Frequency Range | 65Hz – 20kHz (-10 dB) | |
| Transducer Type | 2x 5″ MF (1.26in VC) rubber surround EU transducer 1″ (1.0in VC) HF EU transducer | |
| Dispersion | 60°x60° (HxV) | |
| Crossover Frequency | DSP controlled with selectable presets 48KHz sampling frequency 24 bit AD/DA converter | |
| Max. SPL (peak) | 122dB | |
| Amplifier type | Class D, 2 channel amplifier | |
| Amplifier output | 2x 300W (continuous) | |
| Input | XLR/jack combo connector | |
| Output | XLR/M 3p | |
| Indicators | Power, signal/preset, clip | |
| Controls | Master level control, 4 selectable presets | |
| Feature | Cooling by convection | |
| AC Power Supply | Switching power supply, 85-264Vac with PFC | |
| AC mains connector | Neutrik® powerCON, Power-in (blue) / Power-out (grey) | |
| Protection | Over current and short circuit protection, thermal protection, DC output protection and HF protection (amplifier) | |
| Construction | 15mm birch plywood, textured polyurea coating | |
| Grille | Custom perforated metal grille w/ acoustic mesh | |
| Installation / Rigging / Flying | 8x M8 inserts for “U” brackets, WB205H and WB205V Ø35mm pole mount adapter, PMA205 | |
| Dimensions (WxDxH) | 170x230x430mm 6.69×16.93×9.06in | |
| Weight | 9.5Kg 20.95lb |
