Opis
Key Features
- Bass reflex installation subwoofer
- Available in passive/active versions
- 1x 8″ (1.5in VC) LF EU transducer
- 200W AES / 400 Program power
- 2x NL4 connectors in parallel
- Active version driven by class D amplifier, variable X-over frequency
- Versatile, compact to permit unobtrusive placement
- Supplied with wallmount brackets
- Rugged and durable 15mm birch plywood construction
- Powder coated custom perforated steel grille
Tech Specs
| Type | Compact PASSIVE subwoofer | |
| Enclosure Design | Bass reflex | |
| Power Output (RMS) | 200W (AES) 400W (Program) | |
| Frequency Range | 40Hz – 160Hz (-10dB) | |
| Nominal Impedance | 8 Ohm | |
| Transducer Type | 8″ (1.5in VC) LF European transducer | |
| Max. SPL (peak) | 115dB @ 1m (continuous) 121dB @ 1m (peak) | |
| Connector | 2x NL4 in parallel | |
| Construction | 15mm birch plywood with polyurea coating | |
| Grille | Custom perforated metal grille w/ acoustic foam | |
| Installation / Rigging / Flying | 4 rubber feet Wallmount brackets (supplied) | |
| Dimensions (WxDxH) | 400x215x400mm 15.75×8.46×15.75in | |
| Weight | 11Kg 24.25lb |
