Opis
Key Features
- Bass reflex installation subwoofer
- Active version with premium quality EU amplifier
- 1x 8″ (1.5in VC) LF EU transducer
- 320W rms class D, single channel amplifier
- 85-264Vac universal mains, SMPS, all electronic protections
- Variable X-over frequency adjustable by rotary pot
- Supplied with wallmount brackets
- Rugged and durable 15mm birch plywood construction
- Powder coated custom perforated steel grille
Tech Specs
| Type | Compact ACTIVE subwoofer | |
| Enclosure Design | Bass reflex | |
| Power Output (RMS) | 200W (AES) 400W (Program) | |
| Frequency Range | 40Hz – 160Hz | |
| Nominal Impedance | N/A | |
| Transducer Type | 1x 8″ LF (1.5in VC) EU transducer | |
| Crossover Frequency | Adjustable by potentiometer, 40Hz – 160Hz | |
| Max. SPL (peak) | 115dB @ 1m (continuous) 121dB @ 1m (peak) | |
| Amplifier type | Class D, single channel amplifier | |
| Amplifier output | 320W (continuous) | |
| Input | XLR/F 3p connector | |
| Output | XLR/M 3p connector | |
| Indicators | Power on/off | |
| Controls | Master level control, X-over frequency | |
| AC Power Supply | Switch mode power supply, 85-264Vac with PFC | |
| AC mains connector | Neutrik® powerCON, Power-in (blue) / Power-out (grey) | |
| Protection | Over current, short circuit, thermal protection DC output protection and HF protection (amplifier) | |
| Construction | 15mm birch plywood, textured polyurea coating | |
| Grille | Custom perforated metal grille w/ acoustic foam | |
| Installation / Rigging / Flying | 4 wood feet Prepared for wallmount | |
| Dimensions (WxDxH) | 400x215x400mm 15.75×8.46×15.75in | |
| Weight | 13Kg 28.67lb |
