Key Features
- 2-way multipurpose passive speaker
- 12” (3in VC) MB drivers with high power handling capabilities
- 1,4” (2.56in VC) Neodymiun high frequency driver
- User-rotatable CD horn 90°x60° for ideal dispersion
- Dual NL4 connectors + NL4MPR (for stage monitor)
- Elegant, refined and compact design
- Integrated rigging system, Ø35mm pole mount socket with 5° tilt
- Rugged and durable 15mm birch plywood
- Suited for FOH, High-end monitor, Frontfill systems
- Expandable with subs for a powerful front PA
Tech Specs
Type | 2-Way passive multipurpose speaker | |
Enclosure Design | Bass reflex trapezoidal enclosure | |
Power Output (RMS) | 500W (RMS) 780W (Program) 2000W (Peak) | |
Frequency Range | 52Hz – 19kHz (+/-10dB) | |
Nominal Impedance | 8Ohm | |
Transducer Type | 12″ MF (3in VC) EU transducer 1.4″ Neodymium HF (2.56in VC) EU transducer | |
Dispersion | CD horn, 90°x60° and 60°x90° User-rotatable | |
Crossover Frequency | 1200Hz | |
Max. SPL (peak) | 127dB @ 1m | |
Connector | 2x NL4 in parallel 1x NL4MPR for stage monitor | |
Construction | 15mm brich plywood, textured polyurea coating | |
Grille | Custom perforated metal grille with acoustic foam | |
Installation / Rigging / Flying | Ø35mm pole mount with 5° tilt 5x M8 flying points Wallmount bracket available | |
Dimensions (WxDxH) | 370x350x630mm 14.57×13.78×24.80in | |
Weight | 28Kg 61.73lb |
