DLP15

The DUAL PRO series speaker range offers high-quality 2-way, elegant, refined and wedge shaped enclosures. Designed to deliver nothing but high performances this DLP15 incorporates 15” (3in) midbass transducers with high power handling capabilities combined with a 1.4” (2.56in) NEO driver coupled to a CD horn to ensure a precise audience coverage, improved sound quality and outstanding speech
intelligibility. The dispersion of the CD horn is symmetric and rotatable 90°x60° or 60°x90° in order to keep the same coverage in case of horizontal use as the DLP enclosures offer a monitor wedge shape in case of use as a stage monitor.

Want a discount? Become a member!
Add to Wishlist
Pobierz

Opis

Key Features

  • 2-way multipurpose speaker
  • 15” (3in VC) MB drivers with high power handling capabilities
  • 1,4” (2.56in) Neodymiun high frequency driver
  • User-rotatable CD horn 90°x60° for ideal dispersion
  • Dual NL4 connectors in parallel + NL4MPR (for stage monitor)
  • Elegant, refined and compact design
  • Integrated rigging system, Ø35mm pole mount socket with 5° tilt
  • Rugged and durable 15mm birch plywood
  • Suited for FOH, High-end monitor, Frontfill systems
  • Expandable with subs for a powerful front PA

Tech Specs



Type2-Way passive multipurpose speaker
Enclosure DesignBass reflex trapezoidal enclosure
Power Output (RMS)500W (RMS)
780W (Program)
2000W (Peak)
Frequency Range49Hz – 19kHz (+/-10dB)
Nominal Impedance8Ohm
Transducer Type15″ MF (3in VC) EU transducer
1.4″ Neodymium HF (2.56in VC) EU transducer
DispersionCD horn, 90°x60° and 60°x90°
User-rotatable
Crossover Frequency1200Hz
Max. SPL (peak)129dB @ 1m
Connector2x NL4 in parallel
1x NL4MPR for stage monitor
Construction15mm brich plywood, textured polyurea coating
GrilleCustom perforated metal grille with acoustic foam
Installation / Rigging / FlyingØ35mm pole mount with 5° tilt
5x M8 flying points
Dimensions (WxDxH)440x390x710mm
17.32×15.35×27.95in
Weight31Kg
68.34lb

Dodatkowe informacje

Marka

MOOSE sound

Zastosowania

Instytucje kultury, Kluby muzyczne, Rental
