Key Features
- Front loaded array element, passive
- Trapezoidal enclosure
- 12″ MF (3in VC) + 1.4″ HF NEO (2.56in VC) EU transducers
- 2x NL4 connected in parallel
- Bi-amp operation
- High performance and crystal clear reproduction
- Faithful dynamic response and great range
- Integrated rigging system for stacked and flown configurations
- Rugged and durable 15mm birch plywood construction
- Powder coated custom perforated steel grille
Tech Specs
| Type | 2-way line array element | |
| Enclosure Design | Trapezoidal array enclosure | |
| Power Output (RMS) | 650W (RMS) 780W (Program) 1500W (Peak) | |
| Frequency Range | 62Hz – 20kHz (-10dB) | |
| Nominal Impedance | 8Ohm | |
| Transducer Type | 12″ MF (3in VC) EU transducer 1.4″ HF NEO (2.56in VC) EU transducer | |
| Dispersion | Horizontal: 100° Vertical: 7° | |
| Crossover Frequency | 1600Hz Bi-amp operation, user-selectable | |
| Max. SPL (peak) | 132dB @ 1m | |
| Connector | 2x NL4 in parallel | |
| Construction | 15mm brich plywood, rugged polyurea coating | |
| Grille | Custom perforated metal grille with protective foam | |
| Installation / Rigging / Flying | Integrated rigging flyware Splay angle adjustable, 8° (1° increments) Ø9.8mm ball pins w/ stainless steel lanyard with PVC | |
| Dimensions (WxDxH) | 640x505x330mm 25.20×19.88×12.99in | |
| Weight | 29Kg 63.93lb |
