LA28

Compact vertical line array element designed to provide high performance, detailed highs and a well-defined midrange. The LA28 is a front loaded enclosure, curvilinear array, that features an internal passive crossover, prepared for bi-amp operation, having built-in premium quality EU transducers (2x 8″ – 2in VC) and 1x 1.4″ – 2.56 VC Neodymium HF drivers, both combinations ensuring powerful and crystal clear reproduction, high SPL with an extended frequency response. The MF/HF pattern control is array splay dependent and horizontal coverage is 100° x array length-splay dependent (HXV) thanks to true wave guide horn that ensure consistent and long range projection with very low distortion levels.

Want a discount? Become a member!

Opis

Key Features

  • Ultra-Compact 2-way curvilinear array module
  • Exceptional pattern control due to symmetrical design
  • 2x 8” (2in VC) MF + 1.4” (2.56in VC) Neodymium HF driver
  • 2x NL4 connected in parallel
  • Bi-amp operation
  • High performance and crystal clear reproduction
  • Faithful dynamic response and great range
  • Integrated rigging system for ground stacking and flown configurations
  • Rugged and durable 15mm birch plywood construction
  • Touring sound reinforcement for small and mid-sized venues

Tech Specs

Type2-way curvilinear array element
Enclosure DesignTrapezoidal array enclosure
Power Output (RMS)500W (RMS)
800W (Program)
1600W (Peak)
Frequency Range62Hz – 19.5kHz (-10dB)
Nominal ImpedanceMF: 8Ohm
HF: 8Ohm
Transducer Type2x 8″ (2in VC) MF EU transducer
1.4″ (2.56in VC) Neodymium HF EU transducer
DispersionHorizontal: 100°
Vertical: array length-splay dependent
Crossover Frequency1600Hz
Bi-amp operation, user selectable
Max. SPL (peak)128dB @ 1m
Connector2x NL4 in parallel
Construction15mm brich plywood, rugged polyurea coating
GrilleCustom perforated metal grille with acoustic foam
Installation / Rigging / FlyingIntegrated rigging flyware
Splay angle adjustable, 8° (1° increments)
Ø9.8mm ball pins w/ stainless steel lanyard with PVC
Dimensions (WxDxH)640x480x235mm
25.19×18.89×9.25in
Weight25Kg
55.16lb

Dodatkowe informacje

Marka

MOOSE sound

Zastosowania

Instytucje kultury, Kluby muzyczne, Rental

Specyfikacja

Pobierz plik
